Table of Contents
Chapter 1: TITAN detachable gooseneck lowboy trailer
1-1. What are the types of TITAN rgn lowboy trailer?
1-2. Operation test of detachable gooseneck semi trailer
1-3. TITAN operation test of detachable gooseneck semi trailer
1-4. TITAN rgn trailer specs, capacity, dimension and drawing
1-5. TITAN detachable gooseneck lowboy trailer package
1-6. What is the difference between lowbed trailer and detachable gooseneck lowboy trailer?
1-7. TITAN detachable gooseneck lowboy trailer feedback from Guinea customer
1-8. How does a lowboy semi trailer work?
Chapter 2: RGN trailer(detachable gooseneck trailers)
2-1. What is a lowboy trailer?
2-2. Two structural styles of detachable gooseneck trailer.
2-3. Detachable gooseneck trailers transportation
2-4. Points to consider when purchasing a detachable trailer
2-5. Operation and characteristics of hydraulic lowboy trailer
 |
 |
TITAN - lowboy trailer manufacturers can make the 2/3/4 axles detachable gooseneck lowboy trailers and 3 lines 6 axles heavy duty rgn lowboy trailer, with the capacity of 60/80/100/120/150 ton.
To meet your transport needs and your local regulations, we can customize different configuration removable gooseneck lowboy trailer for you.
Through the video below, you can learn about different types of lowboy semi-trailers(like 3 axle detachable gooseneck lowboy trailers, 4 axle lowboy trailer, 3 line 6 axle heavy duty lowboy trailer, folding gooseneck trailer)
And the process, testing, packaging and customer feedback, etc.
TITAN 3 axle detachable gooseneck 80 ton lowboy trailer for sale
TITAN 4 axle 100 ton removable gooseneck semi trailer
Features of removable gooseneck lowboy semi trailer:
1. Strong carrying capacity
TITAN 4 axle lowboy trailer main beam of TITAN is made of HG60 high-strength structural steel. The yield strength of HG60 steel is ≥ 620MPa, which is more durable and stronger than ordinary steel. Its bearing capacity is 5 times of that of Q345 steel trailer. TITAN lowboy gooseneck trailer for sale adopts reinforced the gooseneck and upper and lower plate by double layer.
2. Low center of gravity and good stability
Due to the low ground clearance and low longitudinal beam height of rgn trailer for sale, the load-bearing surface is 300-400mm lower than that of the normal concave-center removable lowboy semi-trailer, thereby effectively reducing the height of the center of gravity of the loaded goods and improving the stability during transportation.
TITAN lowboy gooseneck trailer for sale bottom plate, Other suppliers usually use 3 or 4 mm bottom plate, But TITAN lowboy equipment trailers adopt 5 mm thick bottom plate, It’s more durable and won’t be deformed.
3. The effective length of the cargo bed is long
Because this type of model eliminates the rear ladder, the bearing surface can be lengthened, and because the construction machinery does not go from the rear, the slope angle in front of the bridge can be appropriately increased, so that the bearing surface can be lengthened. The length of the low flat cargo table with a ladder at the end is longer, which can effectively load more loads, indirectly improve the loading efficiency, and create greater benefits for users.
4. Easy operation
The lifting operation handle of the bearing surface mostly adopts the centralized electric control device, rather than the traditional handle to control the operation, so that the operation interface is more convenient.
TITAN hydraulic system has undergone five major system upgrades in the ten-year production process, and now the hydraulic system has very good stability and stability The customer only needs regular maintenance. It can be used for ten years.
Because 80 ton lowboy trailer has a low center of gravity and a long cargo table, it can transport a lot of goods. Such as some large machinery and equipment, such as pile drivers, large rotary drills, large excavators, and large bulldozers, have very high centers of gravity due to their very high height.
As you can see, the heavy duty lowboy trailer can transport ultra-high and medium sized equipment and machine.
The picture below is feedback from customer who bought TITAN 150T lowboy trailer:
After the production of all hydraulic detachable goosenecks, pressure tests will be performed.
And we have made a video of the specific operation steps of the lowboy trailer for you, such as how to separate the gooseneck from the body, how to adjust the gooseneck height, etc.
Most popular 3 axle detachable gooseneck 60 ton lowboy trailers for sale
TITAN 3 axle detachable gooseneck lowboy trailer drawing
Overall dimension：16000mm * 3000mm *2500mm
Loading capacity: 60 ton lowboy trailer for sale
Axles：3 axles
Tire：12 units
Suspension：Heavy duty mechanical suspension
King pin：50#, 90#
Landing gear：JOST
Goose neck: Hydraulic removable gooseneck
Brake system: WABCO valve
Hydraulic power station: 12KW Diesel engine
Electrical system: 24V, LED lights
More Technical Parameter Drawings
2 axle detachable gooseneck lowbody trailer drawing
3 axle lowboy trailer with 2 axle dolly technical specification
4 axle lowboy trailer front loading technical parameter drawing
3 line 6 axle removable gooseneck lowboy trailer drawing
5 line 10 axle lowboy detachable trailer for sale drawing
4 axle folding gooseneck lowboy trailers drawing
To prevent the extendable gooseneck trailer paint from being corroded by seawater, we spray a layer of wax on the surface of the 3 axle lowboy trailer before shipping, and then seal it with a waterproof rain cloth.
Loading with lowbed trailers, you cannot lower it any further. That means you can’t work without auxiliary equipment for lifting cargo and loading it onto the trailer. For that matter, it will limit you to the type of cargo that you can carry on lowbed trailers.
With RGN trailers, you don’t have to be worried about this since you can almost carry all types of cargo. Characteristics of detachable gooseneck lowboy trailer are that it can be detached from the front unlike with a lowbed semi trailer. This feature has been provided in an RGN trailer for sale to enhance loading and offloading of cargo. The user has an easy time during such occasions. This is unlike for a lowbed semi trailer that load the cargo from rear. It is possible to carry heavy motorized machinery since the trailer can be lowered to its ramp. The appropriate trailer to choose depends on the cargo type that you want to handle.
Owing to these notable characteristics, the RGN trailer for sale is easy to load. This capability enhances the efficiency of the detachable gooseneck lowboy trailer over that of the lowbed trailer.
Passed all aspects of weight test and connection test. We packed the 3 axle lowboy trailer with rain cloth to prevent moisture. We also provide some spare parts to our customers.
Recently, we received feedback from our customers and there is no doubt that the customer is satisfied with our semi trailer. Most importantly, he is willing to introduce his good friends to order and buy semi trailer from us.
Pay attention to something of the lowboy gooseneck trailer for sale:
Cargo weight: Please select the correct model to transport your cargo. If you plan to transport more than 60 tons of cargo, please consider buying a lowboy equipment trailers.
The 100 ton lowboy trailer has a high load capacity and can transport heavy objects. In addition, the lower deck ensures that heavy objects remain stable during transportation.
Cargo dimension: It is important to consider the dimensions of your cargo when choosing a detachable trailer model. Consider the width and height, especially if your country has height limitations for transportation vehicles.
Loading process: Although lowboy equipment trailers are very suitable for loading heavy goods, if you use lifting equipment, ordinary trailers may be the best choice. Most low-bed trailers are loaded from the front or rear.
When you need to remove the gooseneck from the tractor so that the gooseneck remains attached to the lowboy semi trailer frame. Secure the safety hook with a pin to fix the gooseneck in place and prevent the gooseneck from tipping forward.
TITAN 50 ton lowboy trailer for sale customer feedback
How to detach the lowboy gooseneck trailer?
When preparing to remove the gooseneck, you must first link the towing pin with the towing saddle. There are many types of removable gooseneck lowboy trailers. Most split gooseneck operating principles are the same.
1. Remove the positioning pin and the air pipe and wire connection.
2. As the gooseneck height decreases, the bottom angle of the front end of the 100 ton lowboy trailer lowers to the ground and rests on the ground. Once all the linkages have been safely removed, lower the cargo platform.
3. Drive the gooseneck with the truck and drive the tractor far enough away.
4. After driving off the truck, you can now load comfortably from the front of the trailer platform.
Lowboy trailer for sale has many different names in different countries around the world, such as RGN trailer, detachable gooseneck trailer, folding gooseneck lowboy trailers, hydraulic low bed trailer, removable gooseneck trailer, front loading rgn lowboy trailer, and military lowboy trailer for sale.
The hydraulic detachable gooseneck trailer uses a concave beam type. Detachable gooseneck trailer can separate the gooseneck from the trailer, and achieve contact between the front end of the vehicle and the ground. After the cargo or equipment is loaded, the RGN trailer is restored to the original transportation state in time for transportation.
Common low bed semi trailer, should use the ramp behind the trailer for cargo loading. Yet, some large machinery and equipment, such as pile drivers, large rotary drills, large excavators, and large bulldozers, have very high centers of gravity due to their very high height. There is a great risk of later loading.
Loading method for gooseneck trailer: cargo is loaded from the front. Detachable gooseneck cargo table is very low, so the stability and security are very good. As you can see, the 60 ton lowboy trailers for sale can transport ultra-high and medium sized equipment and machine.
TITAN removable gooseneck lowboy trailer dimensions can be customized according to your requirements.
Common detachable gooseneck trailer. It is mainly designed to transport 50 ton lowboy trailer for sale, 60 ton lowboy trailers for sale, 80 ton lowboy trailer, 100 ton lowboy trailer, 120 tons of heavy equipment or machinery. And the main styles are 2 axles, 3 axles, and 4 axles.
Heavy duty rgn lowboy trailer manufacturers. It is mainly designed to transport 100 tons, 120 tons, 150 tons of heavy equipment or machinery. The main use is the line axle structure. 2 lines 4 axles, 3 lines 6 axles, and 4 lines 8 axles.
After the production of all hydraulic detachable goosenecks, pressure tests will be performed.
To prevent the extendable gooseneck trailer paint from being corroded by seawater, we spray a layer of wax on the surface of the lowboy trailer before shipping, and then seal it with a waterproof rain cloth.
There are a variety of different transport semi trailers in the Chinese transport market, as many of them are locally transported and so common low bed trailers are more. Every city in China is under construction and is basically equipped with construction machinery and equipment, so long-distance transportation of large machines such as heavy excavators is not required.
But, the hydraulic gooseneck trailers produced by TITAN rgn lowboy trailer manufacturers are mainly exported to Central and West African countries such as Nigeria and Tanzania, and more than 200 units have been produced. Technology is mature.
1. What is the difference between the steel used for the detachable goose neck trailer?
Currently, the main steel type used for gooseneck lowboy trailers is HG60. HG60 is high-strength structural steel with high toughness, good fatigue resistance, welding performance and corrosion resistance.
HG60 high strength steel: C≤0.18 Si0.15 ~ 0.40 Mn1.00 ~ 1.70 P≤0.030 S≤0.025 Mo-Cr-Nb0.02 ~ 0.06 V0.03 ~ 0.08 Ni- HG60
Tensile test: Ret≥450MPa Rm570 ~ 720MPa A50≥19
Common lowbed trailers use Q345 manganese steel. Q345 steel cannot be used to transport heavy equipment.
2. Frame of gooseneck hydraulic low bed trailer
The effective load surface length of the frame is generally 5500mm to 9000mm, the width is 3000mm to 36000mm, and the widest can be 4 meters wide.
3. What is the load of the detach trailer for sale?
TITAN can be customized heavy duty lowboy trailer according to actual load requirements. Common design load tonnages are 60 tons, 80 tons, 100 tons, 120 tons, 150 tons, fixed rgn equipment trailer max weight reaches 200 tons.
4. How high off the ground is a lowboy trailer?
The height of the 60 ton lowboy trailer for sale plate can be customized. The common design of the height of the working surface is 850mm, and 800mm and 900mm. The height of the working surface can be controlled by the hydraulic system during actual transportation.
TITAN 3 axle 50 ton lowboy trailer for sale drawing
Mechanically detachable gooseneck operation: In the process of removing the gooseneck, the front gooseneck of the trailer must be separated from the saddle of the truck. After the disassembly is completed, the equipment can be loaded.
Removable gooseneck trailer features: Because this trailer has a low center of gravity and a long cargo table, it can transport a lot of goods. The maintenance cost is also very low, the structure is easy to assemble, and the weight is light. Thus, the rgn trailer for sale near me is the preferred type that many transportation companies sell.
